HDBaseT 4K@60Hz Extender with Bi-directional PoE and Control
Key Features:
- Extends 4K@60Hz (4:4:4) video signals up to 40m (131ft) over Cat6/6a/7
- Extends 1080p high-definition video up to 70m (230ft)
- Supports HDR10 and Dolby Vision for superior color depth and contrast
- Bi-directional PoE (Power over Ethernet) provides power to both units from one end
- Bi-directional IR and RS-232 pass-through for remote device management
- HDCP 2.2 compliant for seamless playback of protected 4K content
- Supports high-bitrate audio formats including Dolby Atmos and DTS:X
- Slim, low-profile chassis for easy installation behind flat-panel displays
ProAV Performance over Long Distances
The 120817X utilizes HDBaseT technology to deliver uncompressed HDMI signals over standard network cabling. This kit is designed to solve the challenges of modern 4K distributions, ensuring that ultra-high-definition content—including 4K@60Hz with full 4:4:4 chroma subsampling—reaches the display without artifacts or signal loss. With support for HDR10 and 18Gbps bandwidth, it is the ideal choice for high-end home theaters, sports bars, and corporate conference rooms that demand peak visual performance.
Flexible Installation with Bi-directional PoE
One of the most installer-friendly features of this kit is its bi-directional Power over Ethernet (PoE) capability. Unlike standard extenders that require a power outlet at both the source and the display, the 120817X allows you to plug the power supply into either the transmitter or the receiver. This is particularly useful in scenarios where there is no available AC outlet behind a wall-mounted TV or inside a cramped projector enclosure, significantly simplifying the wiring architecture.
Comprehensive Control and Compatibility
Managing your AV system is seamless thanks to integrated bi-directional IR and RS-232 pass-through. This allows you to control your source device (like a Blu-ray player or media server) from the display location, or manage the display from the equipment rack. The unit is also fully HDCP 2.2 compliant, ensuring that the latest copy-protected movies and streaming content play back without "handshake" issues. Its rugged, slim design ensures it remains discreet while providing the structural integrity required for long-term, professional use.
