| Type | Condenser (electret bias) |
| Frequency Response | 50 to 17000 Hz |
| Polar Pattern | Supercardioid polar pattern (at 1 kHz) |
| Output Impedance | EIA Rated at 150 Ω (170 Ω actual) |
| Configuration | Output: Active balanced |
| Sensitivity | -34 dBV/Pa (21 mV) / at 1 kHz, open circuit voltage |
| Maximum SPL | 120 dB (1 kHz at 1% THD, 1 kW load) |
| Output Noise | 27 dB SPL (A-weighted) |
| Signal-to-Noise Ratio | 68 dB (referenced at 94 dB SPL at 1 kHz) |
| Dynamic Range | 93 dB (1 kΩ load at 1 kHz) |
| Common Mode Rejection | 45 dB minimum (10 Hz to 100 kHz) |
| Clipping Level | Preamplifier Output (1% THD): -8 dBV (0.4 V) |
| Polarity | 3-Pin XLR: Positive sound pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector |
| Attenuation | Mute Switch: -50 dB minimum |
| Connections | LED IN: Active low (≤1.0 V); TTL compatible; Absolute maximum voltage: -0.7 V to 50 V
LOGIC OUT: Active low (≤1.0 V), sinks up to 20 mA; TTL compatible; Absolute maximum voltage: -0.7 V to 50 V (up to 50 V through 3 kΩ) |
| Power Requirements | 48 to 52 VDC phantom, 8.0 mA |
| Operating Temperature | 0 to 135°F (-18 to 57°C) |
| Storage Temperature | -20 to 165°F (-29 to 74°C) |
| Relative Humidity | 0 to 95% |
| Weight | 0.154 lb (0.069 kg) |
| Dimensions (L x W) | 14.8 x 0.7 (37.6 x 1.9 cm) |
