Luxul Wave 2 AC3100 Dual Band Wireless AP

XAP-1610 APE WAVE 2 AC3100 DUAL-BAND ACCESS POINT

The XAP-1610 is built with leading edge 802.11ac Wave 2 technology which offers support for more connected devices and increased data rates, delivering outstanding WiFi performance. It is compatible with all Luxul WiFi controllers, both standalone and embedded, and can be used standalone or as part of a multi- AP deployment. Installation is simple, requiring only a single Ethernet cable that delivers both power and data through the integrated PoE+ port.

FEATURES:

• High performance 802.11ac WiFi (data transfers up to 3167Mbps)
• Concurrent Dual-Band Wireless AC
• 2.4 and 5GHz Beamforming
• High output power for maximum coverage
• Compatible with Luxul Roam Assist™ Wireless Controllers
• VLAN support for creating a secure guest network
• Simple and discreet installation
• Up to 4 SSIDs per band for a total of 8 SSIDs
• Single cable installation with PoE (Injector included)
• Great for streaming media or other demanding applications
• Installs on ceiling or wall; or use as a desktop AP
• Three-year limited warranty
• Supports 128 clients
• Wave 2 technology (MU-MIMO)

This package includes:

• Wave 2 AC3100 Dual-Band Wireless AP (1)
• Mounting kit
• Rubber feet
• PoE injector and power cord
• Ethernet cable
• Quick Install Guide

Dimensions & Measurements

• Height: 7.28 in (18.5 cm)
• Length: 7.28 in (18.5 cm)
• Operating Temperature: 32° to 122°F (0° to 50°C)
• Product Weight: 1.5 lbs (0.7 kg)
• Width: 1.71 in (4.3 cm)

Characteristics & Features

• Access Point Location: Indoor
• Antenna Type: 4x4 MU-MIMO Wave 2
• Beamforming
• Connection Type: Wireless
• Power Cord: US Cord
• Power Type: AC, PoE
• ProWatch Type: ProWatch
• Special Features: Kits, ProWatch Capable
• SSID Capability: 8
• Transmit Power (Maximum): 1000mW, 30dBm
• VLAN Compliance: 802.1Q
• Wireless Frequencies: 2.4 GHz, 5GHz
• Wireless Mode: 802.11 a/b/g/n/ac

Certifications & Warranties

• Certifications: FCC, IC, NDAA 889, RCM, RoHS
