Audio Technica System 10 PRO Dual-Channel Receiver

System 10 PRO Dual-Channel Receiver

Key Features:

• 24-bit/48 kHz digital wireless operation for pristine, uncompressed audio quality
• Operates in the license-free 2.4 GHz ISM frequency range away from TV broadcast interference
• Removable receiver units can be mounted remotely up to 328 ft (100 m) via standard Cat5e cables
• Triple-diversity assurance: time, space, and frequency diversity for interference-free stability
• Balanced XLR and unbalanced 1/4" output connectors for each audio channel
• Cascade link feature allows synchronization of up to 5 chassis (10 channels) simultaneously
• Intuitive digital display for simple channel pairing, RF signal monitoring, and battery level indication

Remote Receiver Flexibility

A standout feature of the System 10 PRO receiver is its modular architecture. The individual receiver units can be detached from the main metal chassis and mounted closer to the performance area via standard network cabling, eliminating signal degradation caused by long coaxial antenna runs.

Triple-Diversity RF Reliability

To guarantee drop-out-free signal transmission in dense RF environments, the ATW-R1440 employs frequency diversity (transmitting across two dynamically allocated frequencies), time diversity (sending data in multiple time slots), and space diversity (using dual antennas on each receiver module).
